SHANDONG LINGONG CONSTRUCTION MACHINERY CO.,LTD.
-
CONTENTS
-
A. Diesel engine system
-
A48-4110001003 Block as 8
A49-4110001003
Seal gp-crankshaft 12
A50-4110001003
Filler gp-oil 14
A5-4110001003
Pan gp-oil 16
A6-4110001003
Gage gp-oil level 18
A7-4110001003
Cover gp 20
A8-4110001003
Piston & gp-rod 22
A9-4110001003
Crankshaft gp 24
A10-4110001003
Pulley gp-crankshaft 26
A11-4110001003
Flywheel gp 28
A12-4110001003
.
1
-
2
.
Damper gp 30
A14-4110001003
Muffler gp 32
A15-4110001003
Camshaft gp 34
A17-4110001003
Lines gp-air 36
A19-4110001003
Manifold gp-exhaust 38
A20-4110001003
Cleaner gp-air 40
A21-4110001003 ()
Pump gp-engine oil 42
A22-4110001003
Drive gp-fan 46
A24-4110001003
Fan & guard gp 48
A25-4110001003
Cooler&filter gp-oil 50
A26-4110001003
Cooler gp- oil 54
A27-4110001003
.
-
.
Lines gp-engine oil 56
A28-4110001003
Lines gp-turbocharger oil 58
A29-4110001003
Pump gp-water 62
A30-4110001003
Regulator & gp-housing 64
A31-4110001003
Lines gp-water 66
A33-4110001003
Lines gp-drain 68
A34-4110001003
Support gp-engine 70
A36-4110001003
Compressor gp-air 72
A37-4110001003
Lines gp-air compressor 74
A38-4110001003
Shut-off gp-electrical 76
A42-4110001003 ()
Trunnion gp 78
A44-4110001003
.
3
-
4
.
Filter gp-secondary 80
A45-4110001003
Housing gp-flywheel 82
A47-4110001003
Turbocharger gp 84
A51-4110001003
Plate 86
A52-4110001003
Cover group, cylinder head 88
A53-4110001003
Fastener group, cylinder head 90
A54-4110001003
Engine lifting group 92
A55-4110001003
Gear gp-front 94
A56-4110001003
Exhaust ejection group 96
A57-4110001003
Motor gp 98
A58-4110001003
Alternator gp 100
A59-4110001003
.
-
.
Air intake and exhaust kine group 102
A60-4110001003
Ejector gp-dust 104
A61-4110001003
Pulley group, fan, v-belt group 106
A62-4110001003
Radiator pipes group 108
A63-4110001003
Puel injection lines gp 110
A64-4110001003
Support gp-engine 112
A65-4110001003
Front housing, cover and fastener gp 114
A66-4110001003
Mehanism gp-valve 118
A67-4110001003
Valve cover group 120
A68-4110001003
Cap group, breather 122
A69-4110001003
Fumes disposal group 124
A70-4110001003
.
5
-
6
.
Pump gp-gov 126
.
-
A DIESEL ENGINE SYSTEM
SHANDONG LINGONG CONSTRUCTION MACHINERY CO.,LTD.
-
-
Diesel engine system 8 .
Block as
.
A48-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003068 C02AB-7N6550+C Assembly block Y 1
2 4110001003069 C02AL-4P0623+D Cylinder block N 1
3 4190000536571 C02AL-1105800+A Cylinder jacket Y 6
4 4110000907019 C02AL-6N8001+B Main bearing cap Y 6
5 4110000907020 7C02AL-6N8002+B Main bearing cap Y 1
6 4110000565006 OC02AL-5S6670+C O-ring Y 18
7 4110000565181 C02AL-2W6134+A Sealing ring Y 6
8 4110001003071 C02AL-7S3224+A Screw Y 14
9 4110000186224 C02AL-7M4046+A Bushing Y 4
10 4110000186226 C02AL-8N4110+A Bushing Y 1
11 4110001003070 C02AL-7N7998+A Plate N 1
12 4110000186225 ()C02AL-7W7546+B Shim Y 1
13 4110000186222 C02AL-4B5387+A Plug Y 1
14 4110000565268 C04AL-3B0623+A Plug Y 1
15 4110000186219 C02AL-1S9540+A Pin Y 1
16 4110000186113 U561C-2B0858+A Plug Y 3
17 4110001005016 M5M6214(1/8-27) Plug Y 1
18 4110000186053 U562A-5M6213+A Plug Y 4
19 4110000565215 U382A-2S5658+A Washer Y 14
20 4110000186231 U321A-5S8462+A Stud Y 1
21 4110000186237 B00000285 Ball Y 1
22 4110000186235 U362A-8K1207+A Pin Y 2
.
Diesel engine system 9
-
Diesel engine system 10 .
Block as
.
A48-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
23 4110000186229 U362A-5B7652+A Pin Y 2
24 4110000186234 U362A-8B6349+A Pin Y 2
25 4110000186114 OU641A-3S5496+A O-ring Y 1
26 4110000186233 U561B-7H3171+A Plug Y 1
27 4110000186236 U564C-8M9307+A Plug Y 1
28 4110000186232 U386A-6F7062+A Washer Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 11
-
Diesel engine system 12 .
Seal gp-crankshaft
.
A49-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186033 C02CB-4W0452+A Sealing ring Y 1
2 4110000186034 C02CB-9Y9895+A Sealing ring Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 13
-
Diesel engine system 14 .
Filler gp-oil
.
A50-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186241 C02DL-1W4928+A Fuel pipe Y 1
2 4110000186239 C02DB-7S1803+A Oil filler cap Y 1
3 4110000186094 OU641A-5F3106+A O-ring Y 1
4 4110000186240 U311A-0S1566+A Screw Y 2
5 4110000186242 C02DL-7S1801+A E-circlip Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 15
-
Diesel engine system 16 .
Pan gp-oil
.
A5-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186298 C03AL-4M2969+B Gasket Y 1
2 4110000186293 C03AB-2P1738+A Bracket Y 1
3 4110000565291 C03AL-8S1965+B Gasket Y 1
4 4110001003134 S00007739+02 Oil sump Y 1
5 4110001003072 C03BL-8N3293+C Jointing clamp Y 1
6 4110000186027 U382A-5M2894+A Washer Y 46
7 4110000186171 U311A-0308535+A Screw Y 18
8 4110000186744 U311A-311A009+A Bolt u311a-311a009+a Y 3
9 4110000186742 U311A-311A007+A Bolt u311a-311a007+a Y 20
10 4110000186743 U311A-311A008+A Bolt u311a-311a008+a Y 5
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 17
-
Diesel engine system 18 .
Gage gp-oil level
.
A6-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186379 C03CB-03CB001+A Bracket Y 1
2 4110001003073 C03CB-103CB002+A Oil pipe N 1
3 4110000186376 C03CB-2P2697+A Tube Y 1
4 4110000186389 90U512A-5K9243+A Nipple Y 2
5 4110001003074 C03CB-8S1326+A Nipple Y 1
6 4110000186386 C03CL-03CL012+A Bracket Y 1
7 4110000186381 C03CL-4B0418+A Collet Y 1
8 4110000186027 U382A-5M2894+A Washer Y 2
9 4110000186005 U311A-0S0509+A Screw Y 1
10 4110000186388 U331A-1D4717+A Nut Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 19
-
Diesel engine system 20 .
Cover gp
.
A7-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003075 C04AB-7N8866+A Cover N 1
2 4110001003077 C04AL-7C3906+A Cover N 1
3 4190000536569 C04AL-7N4448+A Air inlet hatch Y 6
4 4190000536570 C04AL-7N8855+A Air inlet hatch Y 6
5 4110000565268 C04AL-3B0623+A Plug Y 6
6 4110000907034 C04AL-3P1896+A Plug Y 13
7 4110000907035 C04AL-3S8313+A Plug Y 7
8 4110000186102 C04AB-1W5300+A Seat Y 12
9 4110000907036 C04AB-8N7782+B Spring seat Y 1
10 4110000907037 C04AL-6N7174+A Cover Y 1
11 4110000186106 C04AL-6N9915+A Inlet valve Y 6
12 4110001003076 C04AL-6N9916+B Exhaust valve Y 6
13 4110000186112 C04AL-1487425+A Valve guide Y 12
14 4110000186110 C04AL-7S7144+A Valve spring Y 12
15 4110000186108 C04AL-7E6167+A Gasket Y 1
16 4110000907038 C04AL-2A4429+D Collet Y 24
17 4110000186111 C04AL-9Y1798+A Sealing ring Y 18
18 4110000186109 C04AL-7N8018+A Sealing ring Y 6
19 4110000186113 U561C-2B0858+A Plug Y 3
20 4110000186053 U562A-5M6213+A Plug Y 1
21 4110000186114 OU641A-3S5496+A O-ring Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 21
-
Diesel engine system 22 .
Piston & gp-rod
.
A8-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003080 C05AL-05AL502+A Piston Y 6
2 4110001003081 C05AL-1006694+A Piston ring Y 6
3 4110001003082 C05AL-1006695+A Piston ring Y 6
4 4110001004005 C05AB-6I0499+A Piston ring c05ab-6i0499+a Y 6
5 4110000186044 C05AL-7N9805+A Gudgeon pin Y 6
6 4110000186040 C05AL-1S9543+A E-circlip Y 12
7 4110000907048 C05AB-8N1721+B Connecting rod Y 6
8 4110000907049 C05AL-8N1720+B Connecting rod Y 6
9 4110000565112 C05AL-1P9956+A Screw Y 12
10 4110000565111 C05AL-5S6348+A Nut Y 12
11 4110000907050 C05AL-8N1849+A Bushing Y 6
12 4110000186042 C05AL-4W5739+A Bearing shell Y 12
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 23
-
Diesel engine system 24 .
Crankshaft gp
.
A9-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003083 C06AB-06AB102+A Crankshaft Y 1
2 4190000536097 C06AL-4W5738+A Bearing shell Y 7
3 4110000565231 C06AL-1W4405+B Crankshaft Y 1
4 4110000186070 C06AL-1003652+A Extension bar Y 2
5 4110000186073 9#C06AL-5H2671+A Woodruff key Y 1
6 4110000186075 U561B-9F2247+A Plug Y 6
www.votai.net whatsapp/wechat: 86-18630852087.
-
Diesel engine system 25
-
Diesel engine system 26 .
Pulley gp-crankshaft
.
A10-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186049 C06BL-7W5698+A Pulley Y 1
2 4110000186048 C06BL-5S9948+A Washer Y 1
3 4110000186050 C06BL-06BL004+A Screw Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 27
-
Diesel engine system 28 .
Flywheel gp
.
A11-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186140 C06CB-06CB031+A Flywheel and ring gear assembly components c06cb-06cb031 Y 1
2 4110000186407 U311A-2M8548+A Screw Y 9
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 29
-
Diesel engine system 30 .
Damper gp
.
A12-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186020 C06DB-1678123+A Absorber Y 1
2 4110001003084 C06DL-9L6261+A Disc Y 1
3 4190000536455 U311A-0S1587+A Screw Y 6
4 4110000186021 U382A-5P8245+A Washer Y 6
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 31
-
Diesel engine system 32 .
Muffler gp
.
A14-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4011000514 GB5783-M10*45EpZn-8.8 Bolt Y 4
2 4110000907069 GB/T6170-M10-ZN.D:B00000769 Nut Y 8
3 4110000907070 GB/T97.1-10-200HV-ZN.D:B00001276 Washer Y 16
4 4110000565295 C08AB-M08AB009A+B Bracket Y 1
5 4110000054158 M10*35-12.9GB5782 01139338 Screw Y 2
6 4110001003086 C08AB-08AB028+B Silencer Y 1
7 4011000050 GB5782-M10*60EpZn-8.8 Bolt Y 2
8 4110000907062 C08AL-M7N2450+A Clamp Y 1
9 4110000186169 C08AB-08AB022+A Front stent welded parts c08ab-08ab022 N 1
10 4013000150 GB6170-M12EpZn-10 Nut Y 4
11 4110000696102 B00001279 Washer b00001279 Y 8
12 4110000907064 GB/T5782-M12*45-10.9-ZN.D:B00000428 Screw Y 4
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 33
-
Diesel engine system 34 .
Camshaft gp
.
A15-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003087 C09AL-09AL001+B Camshaft Y 1
2 4110000186003 C09AL-7S2204+A Extension bar Y 1
3 4110000565299 C09AL-M8S1491+A Thrust washer Y 1
4 4110000186005 U311A-0S0509+A Screw Y 2
www.votai.net whatsapp/wechat: 86-18630852087.
-
Diesel engine system 35
-
Diesel engine system 36 .
Lines gp-air
.
A17-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003091 C12AL-12AL028+A Air vent pipe N 1
2 4110000186194 C12AL-12AL031+A Pipe Y 1
3 4190000536150 C12AL-9S9736+A Hose Y 1
4 4110000186198 C12AL-8N8196+A Tube Y 1
5 4110000186195 C04BL-5S6735+B Spacer Y 1
6 4110000186089 U562A-5M6214+A Plug Y 1
7 4110000186200 B00001583 Clamp Y 2
8 4110000186193 C12AL-1S4295+A Gasket Y 1
9 4110000186135 U311A-1A2029+A Screw Y 6
10 4110000186188 U311A-0S1591+A Screw Y 2
11 4110001003146 U311A-4L9337+A Screw Y 2
12 4110000186688 C12AL-1H7666+B Spacer Y 1
13 4110000186196 C38AL-7L3195+A Screw Y 4
14 4110000186178 C13BL-2N2766+A Nut Y 4
15 4190000536434 B00001724 Plug Y 1
16 4110000186739 B00001814 Washer Y 1
17 4110000186204 B00001706 Plug Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 37
-
Diesel engine system 38 .
Manifold gp-exhaust
.
A19-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003136 S00014138+01 Exhaust manifold Y 1
2 4110000186037 C13AL-9Y1979+A Shim Y 3
3 4110000186178 C13BL-2N2766+A Nut Y 12
4 4110000186182 U382A-2S6160+A Washer Y 11
5 4110000186180 C13BL-6V1426+A Screw Y 9
6 4110000186181 C13BL-6V1427+A Screw Y 2
7 4110000186027 U382A-5M2894+A Washer Y 2
8 4110000565064 C13BL-1M7643+B Spacer Y 1
9 4110000186691 C13BL-6B7469+B Spacer Y 1
10 4110001003142 U321B-1061793+A Stud Y 1
11 4110001003144 U382A-9M6527+A Washer Y 1
12 4110000186690 C13BL-4P3306+A Heat insulation plate c13bl-4p3306+a Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 39
-
Diesel engine system 40 .
Cleaner gp-air
.
A20-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000565109 KLB-14S-000+A Air cleaner Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 41
-
Diesel engine system 42 .
() Pump gp-engine oil
.
A21-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003063 Q/SC646-38*200:B00002373 Rubber hose Y 1
2 4190000536175 C15AL-4N5353+A Pipe Y 1
3 4110000186025 C15AL-2P8746+B Spacer Y 1
4 4110000186029 U311A-0S1590+A Screw Y 3
5 4110000186030 U311A-0S1619+A Screw Y 1
6 4110000186026 U311A-3B1915+A Screw Y 2
7 4110000186027 U382A-5M2894+A Washer Y 4
8 4110000186024 C15AB-4W2448+A Oil pump Y 1
9 4110000186028 C15AL-7W0507+A Gear Y 1
10 4110000565008 U351A-8M5599+A Woodruff key Y 1
11 4110000186029 U311A-0S1590+A Screw Y 1
12 4110000186031 U382A-1P7346+A Washer Y 1
13 4110001003095 C15AB-4W2321+A Fuel pump N 1
14 4110001003096 C15AB-4W2322+A Pump body N 1
15 4110001003094 C15AB-2P6245+A Input shaft N 1
16 4110000907099 C15AB-8S0493+A Shaft Y 1
17 4110000907100 C15AL-2P2546+A Gear Y 1
18 4110000907101 C15AL-2P1781+A Spacer plate Y 1
19 4110000907102 U351A-1B8709+A Key Y 1
20 4011000053 GB5782-M10*90EpZn-8.8 Bolt Y 3
21 4110000907103 C15AB-4N8385+A Pressure reducing valve Y 1
22 4110000907104 C15AL-4N3732+A Cover Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 43
-
Diesel engine system 44 .
() Pump gp-engine oil
.
A21-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
23 4011001079 GB5782-M8*50EpZn-10.9 Bolt gb5782-m8*50epzn-10.9 Y 1
24 4110000907105 GB/T97.1-8-200HV-Y:B00001299 Washer Y 1
25 4110001003099 C15AL-4N4054+A Fuel pump N 1
26 4110000907107 C15AL-8S6511+A Bearing bushing Y 4
27 4110001003100 C15AL-8N8635+A Fuel pump N 1
28 4110000907109 GB/T308-10:B00000273 Ball Y 1
29 4110000907110 C15AB-2P1170+A Shaft Y 1
30 4110001003098 C15AL-2P0691+A Input shaft N 1
31 4110000907112 C15AL-2P2545+A Gear Y 2
32 4110000907113 C15AL-8S0490+A Shaft Y 1
33 4110000907114 C15AL-2P1169+A Shaft Y 1
34 4110000907115 GB/T308-8:B00000284 Ball Y 1
35 4110000907116 U362A-1F1006+A Pin Y 1
36 4110001002015 B00001275 Washer Y 3
37 4110000565009 B00001237 Spring washer Y 3
38 4110000907117 C15AL-15AL001+A Sleeve Y 2
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 45
-
Diesel engine system 46 .
Drive gp-fan
.
A22-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186253 C16AB-16AB001+A Bracket Y 1
2 4110001003102 C16AL-1P9946+A Shaft N 1
3 4110001003101 C16AL-16AL003+A Fan housing Y 1
4 4110000907120 GB/T119-B10*18:B00000132 Pin Y 1
5 4110000565050 C16AL-M1W4407+A Flange Y 1
6 4110000186263 B00000241 Bearing Y 1
7 4110000186262 B00000216 Bearing Y 1
8 4110000186765 B00001456 Sealing ring Y 1
9 4110000186258 C16AL-16AL002+A Spacer Y 1
10 4110000186257 C16AL-8N5305+A Spacer Y 1
11 4110000186256 C16AL-5S7264+A Washer Y 1
12 4120003420008 M101GB1152-89 Grease cup N 1
13 4110000186259 C16AL-16AL004+A Shim Y 1
14 4110001003138 U311A-1A1460+B Screw Y 8
15 4110000186264 U311A-6V4626+A Screw Y 2
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 47
-
Diesel engine system 48 .
Fan & guard gp
.
A24-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186368 ()C16DB-1N3586+A Rivet Y 1
2 4110000186271 U311A-5S7382+A Screw Y 6
3 4110000186272 U382A-8T4896+A Washer Y 6
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 49
-
Diesel engine system 50 .
Cooler&filter gp-oil
.
A25-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003104 C18AB-7W1471+A
Assembly frame Y 1
2 4110000186146 U311A-0T0573+A Screw Y 1
3 4110000186132 U311A-0L2070+A Screw Y 1
4 4110000186699 C18AL-2W4561+B Spacer Y 1
5 4110000907124 C18AB-2P4004+A Oil filter Y 1
6 4110000186026 U311A-3B1915+A Screw Y 1
7 4110000186027 U382A-5M2894+A Washer Y 1
8 4110000186152 OU641A-8M4432+A O-ring Y 2
9 4110000186131 C18AB-8N4457+A Seat Y 1
10 4110000186149 U311A-1D4540+A Screw Y 1
11 4110000186143 U382A-9M1974+A Washer Y 4
12 4110000186148 U311A-1B9575+A Screw Y 3
13 4110000186135 U311A-1A2029+A Screw Y 2
14 4110000186132 U311A-0L2070+A Screw Y 1
15 4110000907125 C18AL-2W5240+A Hose Y 1
16 4190000536199 12C18AL-1T0765+A Screw Y 1
17 4110000186027 U382A-5M2894+A Washer Y 4
18 4110000186134 U311A-0S1588+A Screw Y 3
19 4110000186130 C18AB-7N0165+A Oil cooler Y 1
20 4110000186700 C18AL-5S6051+B Spacer Y 2
21 4110000186150 U561C-3B0551+A Plug Y 1
22 4110000186145 U311A-0L1352+A Screw Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 51
-
Diesel engine system 52 .
Cooler&filter gp-oil
.
A25-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
23 4110000186142 C18AL-7N2705+A End cover Y 1
24 4110000186062 U562A-3J5390+A Plug Y 1
25 4110000186061 U561C-1B5174+A Plug Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 53
-
Diesel engine system 54 .
Cooler gp- oil
.
A26-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186243 C18BB-18BB004B+A Oil cooler Y 1
2 4190000536001 761G-02-105+A Draining valve Y 1
3 4110001003140 U311A-7B3235+B Screw Y 2
4 4110001003143 U382A-5P8245+B Washer Y 8
5 4110000186652 U331A-1D4719+A Nut Y 8
6 4110001003105 C18BL-7N2790+B Attaching bracket Y 1
7 4110000186087 U311A-0L1351+A Screw Y 2
8 4110000186027 U382A-5M2894+A Washer Y 2
9 4110000186701 C18BL-2S0795+B Spacer Y 1
10 4110001003138 U311A-1A1460+B Screw Y 6
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 55
-
Diesel engine system 56 .
Lines gp-engine oil
.
A27-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003107 C19AB-8N7318+C Oil pipe Y 1
2 4110001003106 C19AB-8N7315+B Oil pipe Y 1
3 4110000186314 C19AB-19AB001+A Filter netting Y 1
4 4110000186303 C19AB-2P1739+A Tube Y 1
5 4110000186323 C19AL-4L3641+A Collet Y 1
6 4110000186322 C19AL-2S1541+A Nozzle Y 6
7 4110000186332 OU641A-1142687+A O-ring Y 3
8 4110000186702 C19AL-2M5407+B Spacer Y 1
9 4110000186704 C19AL-8M0904+B Spacer Y 1
10 4110000186320 C19AL-1L5081+A Spacer Y 1
11 4110000186329 U311A-0S1571+A Screw Y 1
12 4110000186027 U382A-5M2894+A Washer Y 1
13 4110001003108 C19AL-7F7590+D Shim Y 1
14 4110000186184 U311A-0S1594+A Screw Y 3
15 4110000186330 U311A-0T0102+A Screw Y 2
16 4110000186315 C19AL-0L0364+A Extension bar Y 1
17 4110000186324 C19AL-5H3204+A Extension bar Y 1
18 4110000186132 U311A-0L2070+A Screw Y 1
19 4110000186135 U311A-1A2029+A Screw Y 1
20 4110000186328 C19AL-8S8874+A Extension bar Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 57
-
Diesel engine system 58 .
Lines gp-turbocharger oil
.
A28-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003062 Q/SC642.3-1-M16*1.5*32:B00002227 Screw Y 1
2 4110000186485 B00001548 Washer Y 2
3 4110000186705 C19BL-1P1255+B Gasket Y 1
4 4011000912 B00000509 Bolt gb5783-m10*30-10.9 N 2
5 4110000186492 B00001277 Washer Y 2
6 4110000997014 GB/T5783-M8*20-B00000631 Bolt Y 1
7 4110000997019 IGB/T6170-M8-Y-B00000793 Nut-b00000793 Y 1
8 4110000907105 GB/T97.1-8-200HV-Y:B00001299 Washer Y 2
9 4110000186477 C19BL-6N6033+A Collet Y 2
10 4110000186280 C19BB-19BB022+A Tube Y 1
11 4110000186466 C19BB-19BB013+A Tube Y 1
12 4110000186488 C19BL-19BL202+A Bracket Y 1
13 4110000186487 C19BL-19BL201B+A Bracket Y 1
14 4110000186027 U382A-5M2894+A Washer Y 2
15 4110000186135 U311A-1A2029+A Screw Y 3
16 4110000186479 OU641A-8M5248+A O-ring Y 2
17 4110000565021 C02BL-4M6480+B Gasket Y 1
18 4110000565021 C02BL-4M6480+B Gasket Y 1
19 4110000186132 U311A-0L2070+A Screw Y 1
20 4110000186483 OU641A-9M4849+A O-ring Y 1
21 4110000186484 B00001545 Washer Y 2
22 4110000781004 B00002177 Screw Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 59
-
Diesel engine system 60 .
Lines gp-turbocharger oil
.
A28-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
23 4110000186489 C19BL-19BL205+A Nipple Y 1
24 4110000186473 OU641A-3K0360+A O-ring Y 3
25 4110000186478 37U511B-8M0505+A Nipple Y 1
26 4110000186480 OU641A-8M5253+A O-ring Y 1
27 4110000186494 C19BL-19BL206+A Collet Y 1
28 4110000186496 B00000589 Screw Y 1
29 4013000248 GB6170-M5-8 Nut Y 1
30 4110000997039 GB/T93-5-B00001251 Washer Y 1
31 4110000186502 B00001783 Washer Y 1
32 4110000186465 C19BB-19BB204+A Tube Y 1
33 4110000036093 Q/SC622-M10*80-10.9:B00002031 Bolt Y 2
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 61
-
Diesel engine system 62 .
Pump gp-water
.
A29-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003110 C20AB-2W8002+E Water pump Y 1
2 4110000186094 OU641A-5F3106+A O-ring Y 1
3 4110000186093 U311A-0T0055+A Screw Y 2
4 4110000186027 U382A-5M2894+A Washer Y 2
5 4110001003111 C20AL-20AL001+D Pump body N 1
6 4110000907189 C20AL-20AL004+B Cover plate Y 1
7 4110000907190 C20AL-20AL002+A Shaft Y 1
8 4110001003133 S00007131+01 Lip seal N 1
9 4110000907192 C20AL-20AL005+A Gasket Y 1
10 4110000907193 C20AL-20AL006A+A Sealing ring Y 1
11 4110001003112 C20AL-20AL003+A Vane N 1
12 4110001003109 C20AB-2W7678+B Bracket N 1
13 4110000907196 GB/T276-6208/C3:B00000220 Bearing Y 2
14 4110000997033 GB/T893.1-80-B00001050 Retaining ring Y 1
15 4110001003113 C20AL-20AL009+B Screw N 1
16 4110000565009 B00001237 Spring washer Y 2
17 4110000565150 B00000505 Screw Y 2
18 4110000186053 U562A-5M6213+A Plug Y 1
19 4110000186222 C02AL-4B5387+A Plug Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 63
-
Diesel engine system 64 .
Regulator & gp-housing
.
A30-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003114 C22AL-22AL010+A Water hose Y 1
2 4110000186267 C22AL-1118010+A Thermostat Y 1
3 4110000186266 C22AB-8N4485+A Valve Y 1
4 4110000186707 C22AL-7N0944+B Spacer Y 1
5 4110000186270 U561B-8T6763+A Plug Y 1
6 4110000186271 U311A-5S7382+A Screw Y 4
7 4110000186272 U382A-8T4896+A Washer Y 4
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 65
-
Diesel engine system 66 .
Lines gp-water
.
A31-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003115 C24AB-8N4112+A Water pipe N 1
2 4110000186709 C24AL-7N0172+B Nipple Y 1
3 4110000186061 U561C-1B5174+A Plug Y 3
4 4110000186062 U562A-3J5390+A Plug Y 1
5 4110000186053 U562A-5M6213+A Plug Y 2
6 4110000565192 C24AL-2P6132+B Spacer Y 1
7 4110000565036 C24AL-7N0200+B Gasket Y 1
8 4110000907203 C24AL-9L1794+B Hose Y 1
9 4190000536427 B00001575 Clamp Y 2
10 4110000186029 U311A-0S1590+A Screw Y 1
11 4110000186060 U311A-0T0065+A Screw Y 1
12 4110000186030 U311A-0S1619+A Screw Y 2
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 67
-
Diesel engine system 68 .
Lines gp-drain
.
A33-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000565312 C26BB-26BB204+B Hose assembly Y 1
2 4110000186537 C26BB-26BB201+A Tube Y 1
3 4110000186536 C26BB-26BB203+A Hose assembly Y 1
4 4110000907144 C26BB-26BB305+A Fuel pipe Y 1
5 4110000997413 Q/SC1294-12-B00001546 Gasket Y 4
6 4110000997109 Q/SC642.1-01-M12*1.25-B00002178 Bolt-b00002178 Y 2
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 69
-
Diesel engine system 70 .
Support gp-engine
.
A34-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000565297 C33AB-33AB101+A Bracket Y 1
2 4110000186290 U311A-0S1585+A Screw Y 6
3 4110001003143 U382A-5P8245+B Washer Y 6
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 71
-
Diesel engine system 72 .
Compressor gp-air
.
A36-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003120 C47AB-47AB003+C Compressor Y 1
2 4110000565251 C82BL-2P0220+B Gasket Y 1
3 4110000186026 U311A-3B1915+A Screw Y 3
4 4110000186338 U311A-0S1589+A Screw Y 2
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 73
-
Diesel engine system 74 .
Lines gp-air compressor
.
A37-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000565298 C47BL-47BL008+B Nipple Y 1
2 4110000186715 C47BL-47BL007+B Elbow connector c47bl-47bl007+b Y 1
3 4110000186344 C47BB-47BB002+A Tube Y 1
4 4110000186357 C47BL-47BL010+A Nipple Y 1
5 4110000186345 C47BB-47BB003+A Tube Y 1
6 4110000186346 C47BB-47BB004+A Pipe Y 1
7 4110000186358 C47BL-47BL011+A Nipple Y 1
8 4110000186717 37C47BL-47BL026+A Elbow joint c47bl-47bl026+a Y 1
9 4110000186342 C47BB-9N3040+A Hose assembly Y 1
10 4110000186361 3790U512C-2N1287+A Nipple Y 1
11 4110000186354 C47BL-47BL005+A Nipple Y 2
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 75
-
Diesel engine system 76 .
Shut-off gp-electrical
.
A38-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003122 C59AL-59AL213+A Magnet Y 1
2 4011000289 GB5783-M6*16EpZn-8.8 Bolt Y 2
3 4015000213 GB93-6EpZn-65Mn Washer Y 9
4 4015000207 GB97.1-6EpZn-300HV Washer Y 9
5 4011000713 GB5782-M6*40-8.8 Bolt gb5782-m6*40-8.8 Y 2
6 4011000101 GB5783-M6*20EpZn-8.8 Bolt Y 2
7 4013000029 GB6170-M6EpZn-9 Nut N 2
8 4110000565255 C59AL-59AL205+A Bracket Y 1
9 4014000124 GB70.1-M6*40EpZn-8.8 Bolt Y 1
10 4110000565294 C59AL-59AL202+A Bracket Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 77
-
Diesel engine system 78 .
() Trunnion gp
.
A42-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003127 C82DZ-2W6757+A Gudgeon pin N 1
2 4110000186157 C82DL-7N9026+A Seat Y 1
3 4110000186155 C82DL-1W1217+A Bushing Y 1
4 4110000186156 C82DL-2P1487+A Damping ring Y 1
5 4110000186158 OU641A-2P1692+A O-ring Y 1
6 4110000186154 C82DL-0L1329+A Screw Y 6
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 79
-
Diesel engine system 80 .
Filter gp-secondary
.
A44-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003135 S00012823+01 Fuel filter Y 1
2 4011000912 B00000509 Bolt gb5783-m10*30-10.9 N 2
3 4110001002015 B00001275 Washer Y 2
4 4110000186093 U311A-0T0055+A Screw Y 1
5 4110000186549 B00002066 Screw Y 2
6 4110001003129 C85AL-85AL201B+B Bracket Y 1
7 4011000902 B00000637 Bolt gb5783-m8*30-10.9 N 2
8 4110000907105 GB/T97.1-8-200HV-Y:B00001299 Washer Y 2
9 4110000036395 GB/T6170-M8-Y:1B00000793 Hexagon nut Y 2
10 4110000186542 D638-000-02+A Fuel filter Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 81
-
Diesel engine system 82 .
Housing gp-flywheel
.
A45-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003130 C92AL-92AL028+A Housing Y 1
2 4110000907184 C92AL-9H5921+C Gasket Y 1
3 4110001003060 761-02-033A+B Bracket Y 2
4 4110000186254 U311A-1A1460+A Screw Y 13
5 4110000186428 B00001942 Screw Y 8
6 4110000186412 U564C-5F0304+A Plug Y 1
7 4110001003145 U386A-2A1162+A Gasket N 1
8 4110000036064 GB/T93-14:B00001241 Washer Y 8
9 4110000186053 U562A-5M6213+A Plug Y 1
10 4110000186394 GB/T119.2 12*24 Pin Y 4
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 83
-
Diesel engine system 84 .
Turbocharger gp
.
A47-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003119 C38AB-38AB005+B Turbocharger Y 1
2 4110000186196 C38AL-7L3195+A Screw Y 4
3 4110000186193 C12AL-1S4295+A Gasket Y 1
4 4110000186178 C13BL-2N2766+A Nut Y 4
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 85
-
Diesel engine system 86 .
Plate
.
A51-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000565268 C04AL-3B0623+A Plug Y 1
2 4110000565022 C02BL-5S8055+B Gasket Y 1
3 4110000186089 U562A-5M6214+A Plug Y 1
4 4110000186087 U311A-0L1351+A Screw Y 3
5 4110000186027 U382A-5M2894+A Washer Y 3
6 4110000186088 U362A-2A3798+A Pin Y 2
7 4110000907022 C02BL-8L8662+C Cover plate Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 87
-
Diesel engine system 88 .
Cover group, cylinder head
.
A52-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003078 C04BL-5S6735+A Shim Y 1
2 4110000186184 U311A-0S1594+A Screw Y 5
3 4110000186399 B00001767 Gasket Y 1
4 4110001003132 S00002851+01 Housing N 1
5 4110000565115 B00000834 Screw gb/t6177-m10-zn.d N 4
6 4110000997080 Q/SC622-M10*30-ZN.D-B00002003 Bolt Y 4
7 4110000186027 U382A-5M2894+A Washer Y 5
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 89
-
Diesel engine system 90 .
Fastener group, cylinder head
.
A53-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186118 C04CL-5B9603+A Screw Y 7
2 4110000186098 C04CL-1B7709+A Screw Y 5
3 4110000186117 C04CL-1D4595+A Screw Y 20
4 4110000565215 U382A-2S5658+A Washer Y 26
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 91
-
Diesel engine system 92 .
Engine lifting group
.
A54-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000565210 B00001284 Washer Y 4
2 4110000907044 C04DL-M8N8721+C Lifting eye Y 1
3 4110001003079 C04DL-M4W8652+B Plate Y 1
4 4110000186078 C04DL-6V1999+A Screw Y 4
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 93
-
Diesel engine system 94 .
Gear gp-front
.
A55-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186678 C07AB-1064497+B Idler gear Y 1
2 4110000907056 C07AL-7W0546+B Idler gear Y 1
3 4110001003085 C07AL-2S6692+A Roller kit N 1
4 4110000186613 C07AL-07AL201B+B Gear Y 1
5 4110000186608 C07AL-1059772+A Idler gear Y 1
6 4110000186681 C07AL-1W4402+B Gear,camshaft c07al-1w4402+b Y 1
7 4110000565083 C07AB-7N4722+B Gear Y 1
8 4110000907058 C07AL-7W0449+B Gear Y 1
9 4110000907059 C07AL-2P1168+A Bushing Y 1
10 4110000186611 C07AL-8N4960+A Extension bar Y 1
11 4110000186614 C07AL-07AL202B+B Anchor plate Y 1
12 4110000907060 GB/T5783-M10*30-10.9:B00000510 Screw Y 4
13 4110000186184 U311A-0S1594+A Screw Y 2
14 4110000186616 U311A-0S1748+A Screw Y 4
15 4110000186617 U331A-5B9079+A Nut Y 1
16 4110000186027 U382A-5M2894+A Washer Y 2
17 4110000186615 U311A-0S1618+A Screw Y 2
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 95
-
Diesel engine system 96 .
Exhaust ejection group
.
A56-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186185 C08BB-08BB106+A Exhaust pipe Y 1
2 4110000907067 C08AL-M8S6783+A Clamp Y 1
3 4110000907068 GB/T5782-M10*50-ZN.D:B00000398 Screw Y 1
4 4110000907069 GB/T6170-M10-ZN.D:B00000769 Nut Y 1
5 4110000907070 GB/T97.1-10-200HV-ZN.D:B00001276 Washer Y 2
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 97
-
Diesel engine system 98 .
Motor gp
.
A57-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003088 C11AB-3T3181+A Starter motor N 1
2 4110000186122 C11AB-3N0539+A Wire Y 1
3 4110000565024 C11AL-4H7869+B Gasket Y 1
4 4110001003089 C11AL-8S2332+C Screw Y 3
5 4110000186100 U382A-2S0736+A Washer Y 3
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 99
-
Diesel engine system 100 .
Alternator gp
.
A58-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186564 U311A-5S7383+A Screw Y 2
2 4110000186566 C11BL-11BL001+A Engine anchorage Y 1
3 4110000186571 U311A-7X0338+A Screw Y 1
4 4110000186572 U382A-7X0574+A Washer Y 3
5 4110000186561 C11BB-9S1240+A Nut Y 1
6 4110000186685 C11BL-11BL002+B Spacing collar c11bl-11bl002+b Y 1
7 4110000186570 U311A-5P2566+A Screw Y 1
8 4110000186565 C11BL-8S4183+B Bar Y 1
9 4110001003137 U311A-0V0375+B Screw Y 1
10 4110001003090 C11BB-11BB007+A Power generator Y 1
11 4110001003141 U311A-8T4835+A Screw N 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 101
-
Diesel engine system 102 .
Air intake and exhaust kine group
.
A59-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186692 C14AL-9S1274+B Washer c14al-9s1274+b Y 1
2 4110000565180 C14AL-0A2926+A Nipple Y 1
3 4110001003093 C13BZ-M2N2766+A Lock nut N 8
4 4110000186452 C12BL-9L5836+A Tube Y 1
5 4110000186221 C12BL-7M1674+A Filter N 1
6 4110000186450 C12BL-5L8855+A Sealing ring Y 1
7 4110000186449 C12BL-5L8854+A Sealing ring Y 1
8 4110001003092 C12BL-12BL057+B Air vent pipe N 1
9 4190000536432 B00001631 Hose Y 1
10 4110000997065 Q/SC1302-91~114-B00001586 Clamp Y 2
11 4110001002015 B00001275 Washer Y 8
www.votai.net whatsapp/wechat: 86-18630852087.
-
Diesel engine system 103
-
Diesel engine system 104 .
Ejector gp-dust
.
A60-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4190000536426 B00001573 Clamp Y 2
2 4110001003063 Q/SC646-38*200:B00002373 Rubber hose Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 105
-
Diesel engine system 106 .
Pulley group, fan, v-belt group
.
A61-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186767 C16BB-16BB007+A Fan clutch c16bb-16bb007+a Y 1
2 4110000186433 OU641A-9F4446+A O-ring Y 1
3 4011000883 B00000407 Bolt gb5782-m10*70-10.9 Y 6
4 4190000536413 IB00000768 Nut -gb/t6170-m10 Y 6
5 4110001002015 B00001275 Washer Y 6
6 4110000907122 C16BB-16BB026+A Pulley Y 1
7 4110000186435 C16BL-16BL019+A Pulley Y 1
8 4110001003103 C16CZ-16CZ005+A V-belt Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 107
-
Diesel engine system 108 .
Radiator pipes group
.
A62-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186443 B00001579 Clamp Y 4
2 4110000186447 B00002444 Hose Y 1
3 4110000186711 C24CL-24CL077+A Water inlet pipe c24cl-24cl077+a Y 1
4 4190000536445 B00002441 Hose Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 109
-
Diesel engine system 110 .
Puel injection lines gp
.
A63-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186512 C26AB-8N7005+A Tube Y 6
2 4110001003117 56C26AB-26AB203+B Oil pipe N 1
3 4110001003116 14C26AB-26AB202+B Oil pipe N 1
4 4110000186526 C26AL-7C3469+A Bracket Y 6
5 4110000186519 12C26AL-1T0416+A Screw Y 6
6 4110000186027 U382A-5M2894+A Washer Y 2
7 4110000186093 U311A-0T0055+A Screw Y 1
8 4110000186188 U311A-0S1591+A Screw Y 1
9 4110001003118 C26AL-1W9169+B Clamp Y 1
10 4110000186527 C26AL-9N3388+A Screw Y 1
11 4110000186533 U382A-4B4274+A Washer Y 1
12 4110000186014 U331A-3S2713+A Nut Y 3
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 111
-
Diesel engine system 112 .
Support gp-engine
.
A64-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000186274 C33BB-8N1214+A Bearing Y 4
2 4110000186275 C33BL-7N5656+A Sleeve Y 2
www.votai.net whatsapp/wechat: 86-18630852087.
-
Diesel engine system 113
-
Diesel engine system 114 .
Front housing, cover and fastener gp
.
A65-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003123 C82AB-6I0923+A Housing N 1
2 4110000186162 C82AL-4P9863+A Gear housing Y 1
3 4110000186166 U321A-9X2485+A Stud Y 6
4 4110001003124 C82AB-82AB102+A Plate N 1
5 4110000186161 C82AL-1W7110+A Bracket Y 1
6 4110001003125 C82AL-82AL102+A Stud Y 3
7 4110000186089 U562A-5M6214+A Plug Y 1
8 4110000186163 C82AL-8N0110+A Gasket Y 1
9 4110000565227 C82AL-1W3900+B Gasket Y 1
10 4110000565194 C82BL-M9N5769+A Cover plate Y 1
11 4110000907152 C82BL-6N7887+C Spacer Y 1
12 4110001003139 U311A-3S2713+A Hexagon nut N 6
13 4110001003126 C82BZ-82BZ601+A Washer N 6
14 4110000907153 C82BL-4N4526+B Cover plate Y 1
15 4190000536479 -U311A-2P3200 Bolt -u311a-2p3200 Y 2
16 4110000565037 C82BL-2P2720+B Gasket Y 1
17 4110000186171 U311A-0308535+A Screw Y 6
18 4110000186132 U311A-0L2070+A Screw Y 15
19 4110000186132 U311A-0L2070+A Screw Y 2
20 4110000186132 U311A-0L2070+A Screw Y 2
21 4110000186132 U311A-0L2070+A Screw Y 1
22 4110000186172 U311A-1C2251+A Screw Y 2
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 115
-
Diesel engine system 116 .
Front housing, cover and fastener gp
.
A65-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
23 4110000186027 U382A-5M2894+A Washer Y 8
24 4110000186170 U331A-6V8801+A Nut Y 8
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 117
-
Diesel engine system 118 .
Mehanism gp-valve
.
A66-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003128 C84AB-8N4576+B Air valve Y 1
2 4110000186096 C84AB-5S5918+A Tappet Y 12
3 4110000565256 C84AL-84AL001+B Tappet Y 12
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 119
-
Diesel engine system 120 .
Valve cover group
.
A67-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000907178 C84BB-M2W1086+B Cylinder head Y 1
2 4110000186214 U311A-0S1617+A Screw Y 15
3 4110000186216 U381A-3B4505+A Washer Y 15
4 4110000186215 C84BL-1331247+A Gasket Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 121
-
Diesel engine system 122 .
Cap group, breather
.
A68-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110000565259 C84CB-M2W9162+A Breather cap Y 1
2 4110000186009 OU641A-4L9564+A O-ring Y 1
3 4011000908 B00000479 Bolt gb5782-m8*120-10.9 N 1
4 4110000997419 Q/SC597-8*26-B00001811 Washer Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 123
-
Diesel engine system 124 .
Fumes disposal group
.
A69-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4011000574 B00000538 Bolt gb5783-m12*25-8.8 N 1
2 4110000565209 B00001278 Washer Y 2
3 4110000186807 B00000772 Bolt b00000772 Y 1
4 4110000186282 C84DL-8N4247+A Clamp Y 1
5 4110000907179 C84DL-84DL004+B Tube Y 1
6 4110000186277 C84DL-2H0374+A Hose Y 1
7 4110000186283 B00001571 Clamp Y 2
8 4110000186279 C47BL-3S8536+A Spacer Y 1
9 4110000186146 U311A-0T0573+A Screw Y 1
10 4110000186027 U382A-5M2894+A Washer Y 1
11 4110000186278 C84DL-3P2404+A Clamp Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 125
-
Diesel engine system 126 .
Pump gp-gov
.
A70-4110001003
-
Key Part No. Description Spare parts Y/N Qty Remarks
1 4110001003131 CP10Z-P10Z002+B Fuel regulator Y 1
-
www.votai.net whatsapp/wechat: 86-18630852087
.
Diesel engine system 127
